SPICA Thermography System

Raise the efficiency of your production

With the SPICA system Intego offers a highly sensitive laboratory system for thermography. The system is based on the SPICA IR camera, which has been specially developed by INTEGO for inspection and measurement tasks and allows fast and non-destructive inspection and localization of defects. The measurement technology and automation can be individually adapted to the different requirements of the production process.

Specifications

• Passive, lock-in and pulse-phase thermography
• Intego Spica 640, Intego Spica 1280 or uncooled IR bolometer camera
wavelength: 3 µm – 5 µm or 7 µm – 14 µm
• Up to 6 different IR lenses for various spatial resolutions
• Automated lens change
• Large field-of-view up to 260 mm x 210 mm (larger on request possible
• Spatial resolution down to 1 µm/px
• Many different excitation sources:
  • Electrical: various DC power supplies up to 440 A and up to 10 kV
  • Optical: flash light, halogen lamp, laser
  • Other: induction, hot air, ultrasonic
• Measurement time from seconds to minutes

Performance data

The system is especially designed for use in research and development and can be flexibly adapted to different fields of application. Of course, the measuring principle can also be transferred to an inline application.

Further options

If you require an individual solution, Intego offers free-of-charge feasibility studies based on sample parts. The prepared study will include a system design with draft specifications and a price estimate. Do not hesitate to contact us directly.
