IR Camera Spica 640 HS and 1280 HS

Camera Technology

Our IR camera Spica is available with 640 x 512 and 1280 x 1024 pixels detector format. Both IR cameras operate in the short- and mid-wave infrared range (SWIR/MWIR, 1.5 - 5.5 µm) and have a high full frame rate of 356 Hz and 180 Hz. The detector material InSb shows high quantum efficiency and excellent homogeneity. The large cold aperture (F/1.5 or F/2) of the cameras results in extraordinary high thermal sensitivity. Thus, low-noise IR images can be recorded at a short integration time. Blurring caused by fast changing scenes is minimized, the highest possible sub frame rates (i.e. short exposure times) of the camera become usable.

Options

Intego offers a variety of standard and special lenses for the Spica cameras:

  • Standard lenses: 8, 15, 28, 50 and 100 mm
  • Microscope lenses: 1x, 2.5x, 5x and 10x
  • Filter solutions: single filters, filter sliders, filter changers

The cameras are compatible to the following options:

  • Lock-in thermography
  • Non-destructive testing
  • Radiometry

Technical Data

Category Specifications SPICA 640     Specifications SPICA 1280
Camera Type SPICA 640 SM HS  SPICA 1280 SM HS
Detector material  Indium antimonide (InSb) Indium antimonide (InSb)
Size of focal plane array 640 x 512 pixels 1280 x 1024 pixels
Pixel pitch 15 µm x 15 µm 10 µm x 10 µm
Spectral range SWIR / MWIR: 1.5 – 5.5 µm or
MWIR: 3 – 5 µm		 SWIR / MWIR: 1.5 – 5.5 µm or
MWIR: 3 – 5 µm
Aperture F/1.5 or F/2.0 F/1.5 or F/2.0
A/D converter resolution 13/14/15 bit 13 bit
Pixel operability > 99.5% (> 99.9 % typical) > 99.5% (> 99.9 % typical)
Maximum full-frame rate 356 Hz  180 Hz
Maximum subframe rate Up to 5000 Hz / 3000 Hz Up to 5000 Hz / 3000 Hz
NETD (20°C, 75% filling degree) < 25 mK  < 20 mK
Integration mode Snapshot (integrate while read / integrate then read) Snapshot (integrate while read / integrate then read)
Integration time tint 1 µs ... 10 ms 1 µs ... 10 ms
Subframe mode Selectable in size and position Selectable in size and position
Image data interface Digital, camera-link medium Digital, camera-link full
Trigger interface TTL-Trigger IN, Trigger-Gate IN, Exposure OUTt, opto-isolated TTL- Trigger IN
Detector cooler Stirling cooler Stirling cooler
Cool-down time 10 minutes (@ 20°C operating  temperature) 10 minutes (@ 20°C operating temperature)
Cooler lifetime > 20 000 h (MTTF) > 20 000 h (MTTF)
Operation temperature 0°C ... 40°C (non-condensing) 0°C ... 40°C (non-condensing)
Casing   Aluminium Aluminium
Dimensions (l x w x h) 240 mm x 120 mm x 120 mm
(without lens)		 248 mm x 120 mm x 135 mm
(without lens)
Weight Approx. 5 kg (without lens) Approx. 5 kg (without lens)
Power supply 24 VDC ≤ 25 W 24 VDC ≤ 25 W

Further option

Perhaps thermography is also the solution for your quality control. Please contact us.
